    Heat Preservation Dissolved Air Flotation Equipment

    Ask Lasest Price
    Brand Name : Longdai
    Model Number : MJQF-1
    Certification : 9001
    Price : Negotiatable
    Payment Terms : T/T, Wechat Pay, Alipay
    Supply Ability : 1000 Sets per Years
    Delivery Time : 3-5 weeks
    • Product Details
    • Company Profile

    Heat Preservation Dissolved Air Flotation Equipment

    Heat Preservation Dissolved Air Flotation Equipment High Productivity Wastewater Treatment


    Presentation

    The air flotation machine is a dissolved air system that generates a large number of fine bubbles in the water, so that the air is attached to the suspended particles in the form of highly dispersed tiny bubbles, resulting in a state where the density is less than that of water. The principle of buoyancy is used to make it float on the water surface to achieve solidification. -Liquid separation water treatment equipment. Air flotation machines are divided into super-efficiency shallow air flotation machines, vortex air flotation machines, and advection air flotation machines. At present, it has applications in water supply, industrial wastewater and urban sewage treatment. The advantages of the air flotation machine are that its solid-liquid separation equipment has the characteristics of low investment, very small footprint, high degree of automation, and convenient operation and management.


    Parameters

    Typeprocessing capacity(M³h)Size(m)dissolved air vessel Size(mm)Motor Power(Kw)Total Weight(Kg)
    LengthWidthHeight
    MJQF-111.50.91.9φ300 h10002.21200
    MJQF-332.71.22.0φ300 h10002000
    MJQF-553.51.52.0φ300 hl5002800
    MJQF-10104.61.72.0φ400 h30004.03600
    MJQF-20206.02.12.2φ400 h30005400
    MJQF-30307.22.42.2φ500 h30005.56300
    MJQF-40408.32.82.2φ500 h30007500
    MJQF-50509.33.22.2φ600 h30007.59100
    MJQF-606010.33.22.2φ600 h300010000
    MJQF-808011.23.52.5φ800 h30001111500
    MJQF-10010012.53.92.5φ800 h30001513000

    Application

    air flotation machine is a kind of equipment to remove suspended solids, grease and various jelly in various industrial and municipal sewage. This equipment is widely used in the treatment of industrial wastewater and municipal sewage such as oil refining, chemical industry, brewing, vegetable oil production and refining, slaughter, electroplating, printing and dyeing.


    ■ Technical Process

    The dissolved gas tank produces dissolved gas water, and the dissolved gas water is released to 5 cubic meters of water to be treated by the decompression of the release device. The air dissolved in the water is released from the water to form tiny bubbles of 20-40um, which combine with the suspended matter in the sewage to make the specific gravity of the suspended matter less than water, and gradually float to the water surface to form scum. There is a scraper system on the water surface to scrape the scum into the sludge tank. The clean water enters the clean pool from the bottom through the overflow tank.


    ■ Main Features

    Air flotation is a dissolved air system that generates a large number of fine bubbles in the water, so that the air adheres to the suspended particles in the form of highly dispersed tiny bubbles, resulting in a state where the density is less than that of water. The principle of buoyancy is used to make it float on the water surface to achieve solid- Liquid separation water treatment equipment. Air flotation is divided into super-effect shallow air flotation, vortex-concave air flotation, and advection air flotation. At present, it has applications in water supply, industrial wastewater and urban sewage treatment. The advantages of air flotation are its solid-liquid separation equipment has the characteristics of low investment, small floor space, high degree of automation, and convenient operation and management.


    Heat Preservation Dissolved Air Flotation EquipmentHeat Preservation Dissolved Air Flotation Equipment


    Why Choose Us?


    1. Longdai has more than 10 years of experience in wastewater and sludge treatment.

    2. We introduce German technology, thus our product is much better than other Chinese manufacturers.,

    3. We have our own R&D center and complete manufacture system.
