China Medical Incinerator System used in hospital Simple
Installation for Disposable waste
Description
Medical waste is mostly composed of plastic products, glass
products and residual medicine. If it is not disposed of, it will
pollute the living environment and bring safety hazards to people's
health. The medical waste incinerator is a stove and equipment for
burning medical waste. Garbage disposal machinery necessary for
hospitals.
The medical waste incinerator consists of four systems: waste
pre-treatment system, incineration system, smog biochemical dust
removal system and gas generator (auxiliary ignition incineration).
The medical waste incinerator integrates automatic feeding,
screening, drying, incineration, dust removal, dust removal, and
automatic control.
The medical waste incinerator adopts high-tech measures of
high-temperature combustion, secondary oxygen addition, and
automatic slag unloading to meet the monitoring requirements for
sewage discharge.
Parameters
| Type | Main Size(mm) | Capacity(kg/ batch) | Inside volume(m3) | power consumption(kw/h) | fuel consumption(L/h) | Equioment Weight(t) |
| ZTFS-25 | 1000X900X1700 | 25 | 2.5 | 2 | 3 | 1. 15 |
| ZTFS-20-40 | 1200X1300X1800 | 20-40 | 3.0 | 2-4 | 3-8 | 2. 2-5.5 |
| ZTFS-20-60 | 1700X1500X2100 | 20-60 | 5.0 | 2-5 | 3-10 | 4. 5-7. 8 |
| ZTFS-50-120 | 2200X2000X2500 | 50-120 | 10.0 | 3-12 | 4-15 | 5.0-11. 5 |
| ZTFS-100-300 | 3000X3500X2900 | 100-300 | 13.0 | 10-30 | 10-40 | 15-25 |
| ZTFS-400-500 | 3000X3700X3200 | 400-500 | 17.0 | 40-50 | 50-60 | 30-45
|
Application
Garbage incinerator is a device for incineration and disposal of
garbage. Garbage is burned in the furnace and becomes exhaust gas
into the secondary combustion chamber. It is completely burned
under the forced combustion of the burner, and then enters the
spray dust collector. After dust removal, it is discharged into the
atmosphere through the chimney. . The garbage incinerator consists
of four systems: garbage pre-treatment system, incineration system,
smoke biochemical dust removal system and gas generator (auxiliary
ignition incineration). It integrates automatic feeding, sieving,
drying, incineration, dust removal, dust removal, and automatic
control.
The garbage incinerator is a kind of harmless treatment equipment
commonly used in the harmless treatment of medical and domestic
wastes and animals. The principle is to use the combustion of coal,
oil, gas and other fuels to incinerate and carbonize the objects to
be treated at a high temperature to achieve the purpose of
disinfection.
Structure
Incinerator body primary combustion chamber, secondary combustion
chamber, cyclone dust collector, chimney, flue, piping system, high
pressure blower, auxiliary pressure induced draft fan, primary
combustion machine, secondary combustion machine, electric control
cabinet, temperature indicator Device, detection device, etc.
Combustion process and brief description:
The garbage enters the inclined downward grate through the feed
hopper (the grate is divided into a drying zone, a combustion zone,
and a burn-out zone). Due to the staggered movement between the
grate, the garbage is pushed downward, so that the garbage passes
through the grate in turn (When the garbage enters from one area to
another, it will play a big turn around) until it burns out and is
discharged out of the furnace. Combustion air enters from the lower
part of the grate and mixes with garbage; high-temperature flue gas
passes through the heating surface of the boiler to produce hot
steam, while the flue gas is also cooled, and finally the flue gas
is discharged after being processed by the flue gas treatment
device.
